This is a preset to be used in Logitech/Saitek panels (Multi Panel, Switch Panel and Radio Panel), through the SPAD.neXt software. The entire configuration was made to be used, preferably, in the Cessna 172 (G1000 NXi) Deault FS2020.
Place the file "Logitech Panels (current version)" in the SPAD.neXt profile folder.
Default location: C:\Users\[seu nome]\Documents\SPAD.neXt\profiles
Feel free to suggest improvements and fixes!
Magnetos: Cessna 172 Standard Operation
Master BAT: Battery
Master ALT: Alternator
Avionics Master: BUS1 + BUS2
Fuel Pump: Fuel Pump
De-Ice: ON/OFF Alt Static Pull
Pitot Heat: Pitot Heat
Close Cowl: OPEN/CLOSE Fuel Shut Pulll
Strobe: ON/OFF as strobe lights
Beacon: ON/OFF a Beacon Light
Nav: ON/OFF Nav
Taxi: ON/OFF taxi lights ]
Landing: ON/OFF Landing Lights
Landing Gear: Parking Brakes
ALT tab: Displays selected altitude and selected vertical speed. The Knob changes selected altitude by ft.
VS tab:Displays selected altitude and selected vertical speed. Knob changes selected vertical speed by ft.
IAS tab:Displays selected autothrottle speed. Knob changes selected speed by kt.
HDG tab:Displays selected heading. Knob changes selected heading by directional degrees
CRS tab:Displays selected course
*Knobs and Buttons
[AP]: Turns autopilot ON/OFF
[HDG]: Turns heading mode ON/OFF
[NAV]: Turns ON/OFF button LNAV
[IAS]: Turns speed mode ON/OFF
[ALT]: Turns altitude mode
[VS]: Turns vertical speed mode ON/OFF
[APR]: Turns approach mode ON/OFF
[REV] - Glade Slope / Reverse Approach
[AUTO THROTTLE]: ON/OFF Flight Director
- Active Short UP = increment a flap tooth
- Active Short DN = dicrement a flap tooth
- Active Long UP = zero flaps
- Active Long DN = full flaps
[Pitch Trim]: UP and DN
NAV1, NAV2, COM1 and COM2: STANDARD usability
[ADF]: STANDARD usability
[DME]: STANDARD usability
[XPDR]: STANDARD usability
- Left Display - By turning the knob, it is possible to change the QNH.
- Right display - Turning the knob, it is possible to change the TRANSPONDER, according to the PEDESTAL operation.
- ACT/STBY- Long press to switch between QNH or QNE (STD).
*TRANSPONDER = STANDARD usability
